Danfoss®

02-341592 | Genuine Danfoss® PVQ Series Piston Pump

NO CORE CHARGE

Free ground shipping
On eligible $100+ orders in the contiguous U.S. Shipping details

Product SKU: 02-341592
Availability: In Stock

Condition New

$2,349.00 - $2,349.00

$2,349.00

$2,349.00 - $2,349.00

$2,349.00

Hurry! only 1 left in stock!

Pickup available at 111 Belton Drive, Suite B. Usually ready in 24 hours

Ask about this product

Product details

Description	PVQ Series Piston Pump
Condition	New
Brand	Danfoss®
Part Number	02-341592

Feature	Code	Description
SERIES	PVQ	INLINE PISTON PUMP, VARIABLE VOLUME, QUIET SERIES
DISPLACEMENT	10	10.5 CC/REV (0.643 CIR), 207 BAR (3000 PSI)
MOUNTING FLANGE	-A2	SAE "A" 2 BOLT
INPUT SHAFT ROTATION	R	RIGHT-HAND ROTATION (CW)
THRU-DRIVE WITHOUT COUPLING	_	NO THRU-DRIVE
PORTS - TYPE AND LOCATION	-SE	STANDARD - INCH O-RING BOSS, 1.625" INLET AND OUTLET, END PORT
SHAFTS - INPUT	3	SPLINED SAE "A" MODIFIED
SEALS	S	BUNA N, STANDARD
PUMP DESIGN NUMBER	-20	20
CONTROL TYPE	-C21	PRESSURE COMPENSTOR 210 BAR
CONTROL OPTIONS	_	WITHOUT ADJUSTABLE MAXIMUM DISPLACEMENT STOP (STANDARD)
CONTROL DESIGN	-12	O-RING SEAL DESIGN
SPECIAL FEATURES	_	NONE

About the manufacturer

In 1933 Mads Clausen (1905–1966) founded Dansk Køleautomatik- og Apparatfabrik, later in 1946 the company name was changed to Danfoss. The first product was an expansion valve for refrigeration units, it was developed after studying imported valves from the US
