Danfoss®

02-341592 | Genuine Danfoss® PVQ Series Piston Pump

NO CORE CHARGE

Free shipping on purchases over $100,
Order within the next Nov 21 for delivery by Nov 24.

Product SKU: 02-341592
Availability: In Stock

$2,579.00 - $2,579.00

$2,579.00

$2,579.00 - $2,579.00

$2,579.00

Hurry! only 1 left in stock!

Pickup available at 111 Belton Drive Unit -B Usually ready in 24 hours

Buy safely, Easy Returns within 30 days.

365 Days warranty

Orders placed before 7-PM EST will ship same business day

Ask about this product

Description: PVQ Series Piston Pump
Condition: New
Brand: Danfoss®
Part Number: 02-341592

Feature	Code	Description
SERIES	PVQ	INLINE PISTON PUMP, VARIABLE VOLUME, QUIET SERIES
DISPLACEMENT	10	10.5 CC/REV (0.643 CIR), 207 BAR (3000 PSI)
MOUNTING FLANGE	-A2	SAE "A" 2 BOLT
INPUT SHAFT ROTATION	R	RIGHT-HAND ROTATION (CW)
THRU-DRIVE WITHOUT COUPLING	_	NO THRU-DRIVE
PORTS - TYPE AND LOCATION	-SE	STANDARD - INCH O-RING BOSS, 1.625" INLET AND OUTLET, END PORT
SHAFTS - INPUT	3	SPLINED SAE "A" MODIFIED
SEALS	S	BUNA N, STANDARD
PUMP DESIGN NUMBER	-20	20
CONTROL TYPE	-C21	PRESSURE COMPENSTOR 210 BAR
CONTROL OPTIONS	_	WITHOUT ADJUSTABLE MAXIMUM DISPLACEMENT STOP (STANDARD)
CONTROL DESIGN	-12	O-RING SEAL DESIGN
SPECIAL FEATURES	_	NONE

Manufacturer information

In 1933 Mads Clausen (1905–1966) founded Dansk Køleautomatik- og Apparatfabrik, later in 1946 the company name was changed to Danfoss. The first product was an expansion valve for refrigeration units, it was developed after studying imported valves from the US

Warranty
First Truck Parts offers a 365-days warranty for all types of parts and in any condition. The warranty applies only to buyers who have placed an order on our website.
